CLIF Data Dictionary
The CLIF Data Dictionary serves as a comprehensive guide to the Common Longitudinal ICU data Format, detailing the structure and purpose of each table within the framework. Designed to standardize and harmonize electronic health record data across multiple institutions, the dictionary outlines the entity-relationship model, variable definitions, and permissible values.
Beta Tables
The table purpose, structure, and field names for beta tables is complete and used in at least one federated CLIF project. The minimum Common ICU Data Elements (mCIDE) for category variables is defined. Actively testing the table’s practical use in projects. Breaking changes unlikely, but backward compatible updates in future minor versions possible
adt Beta
The admission, discharge, and transfer (adt) table is a start-stop longitudinal dataset that contains information about each patient’s movement within the hospital. It also has a hospital_id field to distinguish between different hospitals within a health system.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter | No restriction |
| hospital_id | VARCHAR | Assign a unique ID to each hospital within a healthsystem | No restriction |
| hospital_type | VARCHAR | Maps hospital_id to a standardized list of hospital types | academic, community, LTACH |
| in_dttm | DATETIME | Start date and time at a particular location. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| out_dttm | DATETIME | End date and time at a particular location. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| location_name | VARCHAR | Location of the patient inside the hospital. This field is used to store the patient location from the source data. It is not used for analysis. | No restriction |
| location_category | VARCHAR | Maps location_name to a standardized list of ADT location categories | ed, ward, stepdown, icu, procedural, l&d, hospice, psych, rehab, radiology, dialysis, other |
| location_type | VARCHAR | Maps ICU type to a standardized list of ICU categories | List of ICU categories in CLIF |
Notes:
- ADT represents the patient’s physical location, NOT the patient “status”.
- Procedural areas and operating rooms should be mapped to
Procedural. Pre/Intra/Post-procedural/OR EHR data (such as anesthesia flowsheet records from Labs, Vitals, Scores, Respiratory Support) are not currently represented in CLIF.
Example:
| hospitalization_id | hospital_id | hospital_type | in_dttm | out_dttm | location_name | location_category | location_type |
|---|---|---|---|---|---|---|---|
| 20010012 | ABC | academic | 2024-12-01 10:00:00+00:00 | 2024-12-01 14:00:00+00:00 | B06F | icu | general_icu |
| 20010012 | ABC | academic | 2024-12-01 14:30:00+00:00 | 2024-12-02 08:00:00+00:00 | B78D | ward | |
| 20010015 | ABC | academic | 2024-11-30 16:45:00+00:00 | 2024-12-01 12:00:00+00:00 | B06T | icu | general_icu |
| 20010015 | ABC | academic | 2024-12-01 12:30:00+00:00 | 2024-12-02 07:00:00+00:00 | N23E | procedural | |
| 20010020 | EFG | community | 2024-11-28 09:00:00+00:00 | 2024-11-29 17:00:00+00:00 | B78D | ward |
code status Beta
This table provides a longitudinal record of changes in a patient’s code status during their hospitalization. It tracks the timeline and categorization of code status updates, facilitating the analysis of care preferences and decisions.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| patient_id | VARCHAR | ID variable for each patient encounter | No restriction |
| start_dttm | DATETIME | The date and time when the specific code status was initiated | Example: 2024-12-03 08:30:00+00:00 |
| code_status_name | VARCHAR | The name/description of the code status | Free text to describe the code status |
| code_status_category | VARCHAR | Categorical variable specifying the code status during the hospitalization | DNR, DNAR, UDNR, DNR/DNI, DNAR/DNI, AND, Full, Presume Full, Other |
Notes:
- The
code_status_categoryset of permissible values is under development
Example:
| patient_id | start_dttm | code_status_name | code_status_category |
|---|---|---|---|
| 123451 | 2024-12-01 08:30:00+00:00 | Do Not Resuscitate | DNR |
| 123452 | 2024-12-02 14:00:00+00:00 | Do Not Intubate | DNR/DNI |
| 123451 | 2024-12-03 10:15:00+00:00 | Full Code | Full |
crrt therapy Beta
The crrt_therapy table captures Continuous Renal Replacement Therapy (CRRT) data, including different CRRT modalities, operational parameters, and fluid exchange details. The intermittent HD, peritoneal dialysis, PERT, and SLED tables are under development.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for hospitalization episode | No restriction |
| device_id | VARCHAR | Unique identifier for dialysis machine | No restriction |
| recorded_dttm | DATETIME | Timestamp when CRRT parameters were recorded | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| crrt_mode_name | VARCHAR | Name of CRRT mode (e.g., CVVHDF) | No restriction |
| crrt_mode_category | VARCHAR | Standardized CRRT mode categories | scuf, cvvh, cvvhd, cvvhdf |
| dialysis_machine_name | VARCHAR | Unique identifier for the dialysis machine | No restriction |
| blood_flow_rate | FLOAT | Rate of blood flow through the CRRT circuit (mL/hr) | Numeric values in mL/hr |
| pre_filter_replacement_fluid_rate | FLOAT | Rate of pre-filter replacement fluid infusion (mL/hr) | Numeric values in mL/hr |
| post_filter_replacement_fluid_rate | FLOAT | Rate of post-filter replacement fluid infusion (mL/hr) | Numeric values in mL/hr |
| dialysate_flow_rate | FLOAT | Flow rate of dialysate solution (mL/hr) | Numeric values in mL/hr |
| ultrafilteration_out | FLOAT | Net ultrafiltration output (mL) | Numeric values in mL |
Notes:
- SCUF: Slow Continuous Ultrafiltration
- CVVH: Continuous Veno-Venous Hemofiltration
- CVVHD: Continuous Veno-Venous Hemodialysis
- CVVHDF: Continuous Venous-Venous Hemodiafiltration
CRRT Modalities and Parameter Usage:
| CRRT Modality | Blood Flow Rate | Pre-Filter Replacement Rate | Post-Filter Replacement Rate | Dialysate Flow Rate | Ultrafiltration Out |
|---|---|---|---|---|---|
| SCUF | Required | Not Used | Not Used | Not Used | Required |
| CVVH | Required | Required | Required | Not Used | Required |
| CVVHD | Required | Not Used | Not Used | Required | Required |
| CVVHDF | Required | Required | Required | Required | Required |
Example:
| hospitalization_id | device_id | recorded_dttm | crrt_mode_name | crrt_mode_category | blood_flow_rate | pre_filter_replacement_fluid_rate | post_filter_replacement_fluid_rate | dialysate_flow_rate | ultrafiltration_out |
|---|---|---|---|---|---|---|---|---|---|
| 201 | J3 | 2024-02-15 07:00:00+00:00 | CVVHDF | CVVHDF | 200.0 | 1000.0 | 500.0 | 800.0 | 1500.0 |
| 202 | J7 | 2024-02-16 09:15:00+00:00 | CVVH | CVVH | 180.0 | 1200.0 | 300.0 | NA | 1300.0 |
| 203 | J11 | 2024-02-17 11:45:00+00:00 | SCUF | SCUF | 150.0 | NA | NA | NA | 800.0 |
ecmo mcs Beta
The ECMO/MCS table is a wider longitudinal table that captures the start and stop times of ECMO/MCS support, the type of device used, and the work rate of the device.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for the hospitalization event | No restriction |
| recorded_dttm | DATETIME | Date and time when the device settings and/or measurement was recorded | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| device_name | VARCHAR | Name of the ECMO/MCS device used including brand information, e.g. Centrimag | No restriction |
| device_category | VARCHAR | Maps device_name to a standardized mCIDE | Impella, Centrimag, TandemHeart, HeartMate, ECMO, Other |
| mcs_group | VARCHAR | Maps device_category to a standardized mCIDE of MCS types | List of MCS groups in CLIF |
| device_metric_name | VARCHAR | String that captures the measure of work rate of the device, e.g., RPMs | No restriction |
| device_rate | FLOAT | Numeric value of work rate, e.g., 3000 RPMs | Numeric values |
| sweep | FLOAT | Gas flow rate in L/min | Numeric values in L/min |
| flow | FLOAT | Blood flow in L/min | Numeric values in L/min |
| fdO2 | FLOAT | Fraction of delivered oxygen | Numeric values (0-1) |
Example:
| hospitalization_id | recorded_dttm | device_name | device_category | mcs_group | device_metric_name | device_rate | flow | sweep | fdO2 |
|---|---|---|---|---|---|---|---|---|---|
| 1001 | 2024-01-01 08:00:00+00:00 | Centrimag | CentriMag_LV | temporary_LVAD | RPMs | 3000 | 4.5 | NULL | NULL |
| 1002 | 2024-01-05 12:00:00+00:00 | ECMO VV | VV_ECMO | ECMO | RPMs | NULL | 5.2 | 2.0 | 1.0 |
| 1003 | 2024-01-10 09:00:00+00:00 | TandemHeart | TandemHeart_LV | temporary_LVAD | RPMs | 2800 | 3.8 | NULL | NULL |
| 1004 | 2024-01-15 14:00:00+00:00 | ECMO VA | VA_ECMO | ECMO | RPMs | 3500 | 4.0 | 4.0 | 1.0 |
hospitalization Beta
The hospitalization table contains information about each hospitalization event. Each row in this table represents a unique hospitalization event for a patient. This table is inspired by the visit_occurance OMOP table but is specific to inpatient hospitalizations (including those that begin in the emergency room).
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| patient_id | VARCHAR | Unique identifier for each patient, linking to the patient table | No restriction |
| hospitalization_id | VARCHAR | Unique identifier for each hospitalization encounter. Each hospitalization_id represents a unique stay in the hospital | No restriction |
| hospitalization_joined_id | VARCHAR | Unique identifier for each continuous inpatient stay in a health system which may span different hospitals (Optional) | No restriction |
| admission_dttm | DATETIME | Date and time the patient is admitted to the hospital. All datetime variables must be timezone-aware and set to UTC | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| discharge_dttm | DATETIME | Date and time the patient is discharged from the hospital. All datetime variables must be timezone-aware and set to UTC | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| age_at_admission | INT | Age of the patient at the time of admission, in years | No restriction |
| admission_type_name | VARCHAR | Type of inpatient admission. Original string from the source data | e.g. Direct admission, Transfer, Pre-op surgical |
| admission_type_category | VARCHAR | Admission disposition mapped to mCIDE categories | List of admission type categories in CLIF |
| discharge_name | VARCHAR | Original discharge disposition name string recorded in the raw data | No restriction, e.g. home |
| discharge_category | VARCHAR | Maps discharge_name to a standardized list of discharge categories | Home, Skilled Nursing Facility (SNF), Expired, Acute Inpatient Rehab Facility, Hospice, Long Term Care Hospital (LTACH), Acute Care Hospital, Group Home, Chemical Dependency, Against Medical Advice (AMA), Assisted Living, Still Admitted, Missing, Other, Psychiatric Hospital, Shelter, Jail |
| zipcode_nine_digit | VARCHAR | Patient 9 digit zip code, used to link with other indices such as ADI and SVI | No restriction |
| zipcode_five_digit | VARCHAR | Patient 5 digit zip code, used to link with other indices such as ADI and SVI | No restriction |
| census_block_code | VARCHAR | 15 digit FIPS code | No restriction |
| census_block_group_code | VARCHAR | 12 digit FIPS code | No restriction |
| census_tract | VARCHAR | 11 digit FIPS code | No restriction |
| state_code | VARCHAR | 2 digit FIPS code | No restriction |
| county_code | VARCHAR | 5 digit FIPS code | No restriction |
Notes:
- If a patient is discharged to Home/Hospice, then
discharge_category == Hospice. - The geographical indicators (
zipcode_nine_digit,zipcode_five_digit,census_block_code,census_block_group_code,census_tract,state_code,county_code) should be added if they are available in your source dataset.zipcode_nine_digitis preferred overzipcode_five_digit, andcensus_block_codeis ideal for census based indicators. The choice of geographical indicators may differ depending on the project. - If a patient is transferred between different hospitals within a health system, a new
hospitalization_idshould be created. - If a patient is initially seen in an ER in hospital A and then admitted to inpatient status in hospital B, one
hospitalization_idshould be created for data from both stays. - A
hospitalization_joined_idcan also be created from a CLIF table from contiguoushospitalization_ids.
Example:
| patient_id | hospitalization_id | hospitalization_joined_id | admission_dttm | discharge_dttm | age_at_admission | admission_type_name | admission_type_category | discharge_name | discharge_category | zipcode_five_digit | zipcode_nine_digit | census_block_group_code | latitude | longitude |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 101001 | 12345678 | 22334455 | 2024-11-01 08:15:00+00:00 | 2024-11-04 14:30:00+00:00 | 65 | Direct admission | Inpatient | Discharged to Home or Self Care (Routine Discharge) | Home | 60637 | 606370000 | 170313202001 | 41.81030 | -87.59697 |
| 101002 | 87654321 | 22334455 | 2024-11-04 15:00:00+00:00 | 2024-11-07 11:00:00+00:00 | 72 | Transfer from another hospital | Acute Care Transfer | Transferred to Acute Inpatient Rehab Facility | Acute Inpatient Rehab Facility | 46311 | 463110000 | 170313301002 | 41.55030 | -87.30101 |
| 101003 | 11223344 | 11223344 | 2024-10-20 07:45:00+00:00 | 2024-10-22 10:20:00+00:00 | 59 | Pre-op surgical | Pre-op | Expired | Expired | 60446 | 604460000 | 170313401003 | 41.70010 | -87.60315 |
hospital diagnosis Beta
Record of all diagnoses associated with the hospitalization. Expect breaking changes to this table as we seek to align it with existing diagnosis ontologies
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| patient_id | VARCHAR | Unique identifier for each patient | No restriction |
| diagnostic_code | DOUBLE | Numeric diagnosis code | Valid code in the diagnostic_code_format |
| diagnosis_code_format | VARCHAR | Description of the diagnostic code format | icd9, icd10 |
| start_dttm | DATETIME | Date time the diagnosis was recorded | Datetime format should be YYY-MM-DD HH:MM:SS+00:00 |
| end_dttm | DATETIME | Date time the diagnosis was noted as resolved (if resolved) | Datetime format should be YYY-MM-DD HH:MM:SS+00:00 |
Example:
| hospitalization_id | diagnostic_code | diagnosis_code_format | start_dttm | end_dttm |
|---|---|---|---|---|
| 1001014 | 250.00 | icd9 | 2023-05-01 08:00:00+00:00 | 2023-05-10 08:00:00+00:00 |
| 1001014 | J45.909 | icd10 | 2023-05-01 08:00:00+00:00 | 2023-05-15 08:00:00+00:00 |
| 1002025 | 401.9 | icd9 | 2023-06-10 09:00:00+00:00 | 2023-06-12 09:00:00+00:00 |
| 1002025 | E11.9 | icd10 | 2023-06-10 09:00:00+00:00 | 2023-06-20 09:00:00+00:00 |
| 1003036 | 414.01 | icd9 | 2023-07-15 07:30:00+00:00 | 2023-07-30 07:30:00+00:00 |
| 1003036 | I25.10 | icd10 | 2023-07-15 07:30:00+00:00 | 2023-07-25 07:30:00+00:00 |
| 1004047 | 530.81 | icd9 | 2023-08-20 10:00:00+00:00 | 2023-08-22 10:00:00+00:00 |
| 1004047 | K21.9 | icd10 | 2023-08-20 10:00:00+00:00 | 2023-08-24 10:00:00+00:00 |
labs Beta
The labs table is a long form (one lab result per row) longitudinal table.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter. | No restriction |
| lab_order_dttm | DATETIME | Date and time when the lab is ordered. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| lab_collect_dttm | DATETIME | Date and time when the specimen is collected. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| lab_result_dttm | DATETIME | Date and time when the lab results are available. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| lab_order_name | VARCHAR | Procedure name for the lab, e.g. “Complete blood count w/ diff” | No restriction |
| lab_order_category | VARCHAR | Maps lab_order_name to standardized list of common lab order names, e.g. “CBC” | List of lab order categories in CLIF |
| lab_name | VARCHAR | Original lab component as recorded in the raw data, e.g. “AST (SGOT)”. | No restriction |
| lab_category | VARCHAR | Maps lab_name to a minimum set of standardized labs identified by the CLIF consortium as minimum necessary labs for the study of critical illness. | List of lab categories in CLIF |
| lab_value | VARCHAR | Recorded value corresponding to a lab. Lab values are often strings that can contain non-numeric results (e.g. “> upper limit of detection”). | No restriction |
| lab_value_numeric | DOUBLE | Parse out numeric part of the lab_value variable (optional). | Numeric |
| reference_unit | VARCHAR | Unit of measurement for that lab. | Permissible reference values for each lab_category listed here |
| lab_specimen_name | VARCHAR | Original fluid or tissue name the lab was collected from as given in the source data | No restriction |
| lab_specimen_category | VARCHAR | Fluid or tissue the lab was collected from, analogous to the LOINC “system” component. | working CDE c(blood/plasma/serum, urine, csf, other) |
| lab_loinc_code | VARCHAR | LOINC code for the lab | No restrictions |
Notes:
The lab_value field often has non-numeric entries that are useful to make project-specific decisions. A site may choose to keep the lab_value field as a character and create a new field lab_value_numeric that only parses the character field to extract the numeric part of the string.
Example:
| hospitalization_id | lab_order_dttm | lab_collect_dttm | lab_result_dttm | lab_order_name | lab_order_category | lab_name | lab_category | lab_value | lab_value_numeric | reference_unit | lab_specimen_name | lab_specimen_category | lab_loinc_code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1001014 | 2023-05-01 07:00:00+00:00 | 2023-05-01 07:15:00+00:00 | 2023-05-01 08:00:00+00:00 | Complete blood count w/ diff | CBC | WBC | white_blood_cell_count | 8.2 | 8.2 | 10^3/uL | blood | blood/plasma/serum | 6690-2 |
| 1001014 | 2023-05-01 07:00:00+00:00 | 2023-05-01 07:15:00+00:00 | 2023-05-01 08:00:00+00:00 | Complete blood count w/ diff | CBC | HGB | hemoglobin | 13.5 | 13.5 | g/dL | blood | blood/plasma/serum | 718-7 |
| 1002025 | 2023-06-10 08:30:00+00:00 | 2023-06-10 08:45:00+00:00 | 2023-06-10 09:00:00+00:00 | Basic metabolic panel | BMP | Sodium | sodium | 140 | 140 | mmol/L | blood | blood/plasma/serum | 2951-2 |
| 1002025 | 2023-06-10 08:30:00+00:00 | 2023-06-10 08:45:00+00:00 | 2023-06-10 09:00:00+00:00 | Basic metabolic panel | BMP | Potassium | potassium | 4.2 | 4.2 | mmol/L | blood | blood/plasma/serum | 2823-3 |
| 1003036 | 2023-07-15 06:45:00+00:00 | 2023-07-15 07:00:00+00:00 | 2023-07-15 07:30:00+00:00 | Liver function panel | LFT | AST (SGOT) | ast | 35 | 35 | U/L | blood | blood/plasma/serum | 1920-8 |
| 1003036 | 2023-07-15 06:45:00+00:00 | 2023-07-15 07:00:00+00:00 | 2023-07-15 07:30:00+00:00 | Liver function panel | LFT | ALT (SGPT) | alt | 28 | 28 | U/L | blood | blood/plasma/serum | 1742-6 |
medication admin continuous Beta
The medication admin continuous table is a long-form (one medication administration record per) longitudinal table designed for continuous infusions of common ICU medications such as vasopressors and sedation (Boluses of these drugs should be recorded in med_admin_intermittent). Note that it only reflects dose changes of the continuous medication and does not have a specific “end_time” variable to indicate the medication being stopped. The end of a continuous infusion should be recorded as a new row with med_dose = 0 and an appropriate mar_action_name (e.g. “stopped” or “paused”).
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter | No restriction |
| med_order_id | VARCHAR | Medication order ID. Foreign key to link this table to other medication tables | No restriction |
| admin_dttm | DATETIME | Date and time when the medicine was administered. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| med_name | VARCHAR | Original med name string recorded in the raw data which often contains concentration e.g. NOREPInephrine 8 mg/250 mL | No restriction |
| med_category | VARCHAR | Maps med_name to a limited set of active ingredients for important ICU medications, e.g. norepinephrine | List of continuous medication categories in CLIF |
| med_group | VARCHAR | Limited number of ICU medication groups identified by the CLIF consortium, e.g. vasoactives | List of continuous medication groups in CLIF |
| med_route_name | VARCHAR | Medicine delivery route | e.g. IV, enteral |
| med_route_category | VARCHAR | Maps med_route_name to a standardized list of medication delivery routes | Under-development |
| med_dose | FLOAT | Quantity taken in dose | Numeric |
| med_dose_unit | VARCHAR | Unit of dose. It must be a rate, e.g. mcg/min. Boluses should be mapped to med_admin_intermittent | No restriction |
| mar_action_name | VARCHAR | MAR (medication administration record) action, e.g. stopped | No restriction |
| mar_action_category | VARCHAR | Maps mar_action_name to a standardized list of MAR actions | Under-development |
Example:
| hospitalization_id | admin_dttm | med_name | med_category | med_group | med_route_name | med_route_category | med_dose | med_dose_unit | mar_action_name |
|---|---|---|---|---|---|---|---|---|---|
| 792391 | 2123-11-13 12:28:00+00:00 | PROPOFOL 10 MG/ML INTRAVENOUS EMULSION | propofol | sedation | Intravenous | NA | 75.0000 | mcg/kg/min | New Bag |
| 792391 | 2123-11-13 13:49:00+00:00 | REMIFENTANIL CONTINUOUS IV (ANESTHESIA) | remifentanil | sedation | NA | NA | 0.0500 | mcg/kg/min | New Bag |
| 792391 | 2123-11-13 14:03:00+00:00 | PROPOFOL 10 MG/ML INTRAVENOUS EMULSION | propofol | sedation | Intravenous | NA | 0.0000 | mcg/kg/min | Stopped |
| 370921 | 2123-02-12 03:07:00+00:00 | PHENYLEPHRINE 5 MG/50 ML (100 MCG/ML) IN 0.9 % SODIUM CHLORIDE | phenylephrine | vasoactives | Intravenous | NA | 20.0000 | mcg/min | New Bag |
| 370921 | 2123-02-12 03:14:00+00:00 | PHENYLEPHRINE 5 MG/50 ML (100 MCG/ML) IN 0.9 % SODIUM CHLORIDE | phenylephrine | vasoactives | Intravenous | NA | 50.0000 | mcg/min | Rate Change |
| 702344 | 2123-04-27 04:30:00+00:00 | HEPARIN (PORCINE) 25,000 UNIT/250 ML IN 0.45 % SODIUM CHLORIDE | heparin | anticoagulation | Intravenous | NA | 18.0000 | Units/kg/hr | New Bag |
microbiology culture Beta
The microbiology culture table is a wide longitudinal table that captures the order and result times of microbiology culture tests, the type of fluid collected, the component of the test, and the organism identified.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter. | |
| order_dttm | DATETIME | Date and time when the test is ordered. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| collect_dttm | DATETIME | Date and time when the specimen is collected. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| result_dttm | DATETIME | Date and time when the results are available. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| fluid_name | VARCHAR | Cleaned fluid name string from the raw data. This field is not used for analysis. | No restriction. Check this file for examples |
| fluid_category | VARCHAR | Fluid categories defined according to the NIH common data elements. | CDE NIH Infection Site |
| method_name | VARCHAR | Original method names from the source data. | No restriction |
| method_category | VARCHAR | Maps method_name to a standardized list of method categories. | culture, gram stain, smear |
| organism_category | VARCHAR | Cleaned organism name string from the raw data. This field is not used for analysis. | No restriction. Check this file for examples. |
| organism_group | VARCHAR | Maps organism_name to the standardized list of organisms in the NIH CDE. | CDE NIH Organism |
Example:
| hospitalization_id | order_dttm | collect_dttm | result_dttm | fluid_name | fluid_category | method_name | method_category | organism_category | organism_group |
|---|---|---|---|---|---|---|---|---|---|
| 12345 | 2023-10-01 14:00:00+00:00 | 2023-10-01 15:00:00+00:00 | 2023-10-03 10:00:00+00:00 | culture, blood (bacterial & fungal) | blood/buffy coat | culture | culture | no growth | no growth |
| 12345 | 2023-10-01 16:00:00+00:00 | 2023-10-01 17:00:00+00:00 | 2023-10-03 12:00:00+00:00 | culture, urine | genito-urinary tract | culture | culture | escherichia_coli | escherichia (also e. coli) |
| 12346 | 2023-11-01 10:30:00+00:00 | 2023-11-01 11:15:00+00:00 | 2023-11-02 09:00:00+00:00 | culture & stain, respiratory | lower respiratory tract | gram stain | gram stain | gram positive cocci | gram positive cocci (nos) |
| 12346 | 2023-11-02 12:00:00+00:00 | 2023-11-02 12:45:00+00:00 | 2023-11-03 08:30:00+00:00 | culture, cerebrospinal fluid | csf | culture | culture | no growth | no growth |
| 12347 | 2023-09-15 14:20:00+00:00 | 2023-09-15 15:00:00+00:00 | 2023-09-17 11:30:00+00:00 | culture & stain, afb | other unspecified | afb smear | smear | no growth | no growth |
| 12348 | 2023-08-10 09:00:00+00:00 | 2023-08-10 09:45:00+00:00 | 2023-08-12 08:00:00+00:00 | culture, blood (bacterial & fungal) | blood/buffy coat | culture | culture | staphylococcus_aureus | staphylococcus (all) |
| 12349 | 2023-07-25 11:00:00+00:00 | 2023-07-25 11:30:00+00:00 | 2023-07-27 10:15:00+00:00 | culture, urine | genito-urinary tract | culture | culture | enterococcus_faecium | enterococcus (all species) |
| 12350 | 2023-06-15 13:30:00+00:00 | 2023-06-15 14:00:00+00:00 | 2023-06-17 09:45:00+00:00 | culture & stain, respiratory | lower respiratory tract | gram stain | gram stain | gram negative rod | gram negative rod (nos) |
microbiology nonculture Beta
The microbiology non-culture table is a wide longitudinal table that captures the order and result times of non-culture microbiology tests, the type of fluid collected, the component of the test, and the result of the test.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for the hospitalization event. | No restriction |
| result_dttm | DATETIME | Date and time when the non-culture result was obtained. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| collect_dttm | DATETIME | Date and time when the sample was collected. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| order_dttm | DATETIME | Date and time when the test was ordered. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| fluid_name | VARCHAR | Name of the fluid sample. | No restriction |
| component_category | VARCHAR | Category of the component tested. | No restriction |
| result_unit_category | VARCHAR | Unit category of the test result. | No restriction |
| result_category | VARCHAR | Category of the test result. | No restriction |
Example:
| hospitalization_id | result_dttm | collect_dttm | order_dttm | fluid_name | component_category | result_unit_category | result_category |
|---|---|---|---|---|---|---|---|
| 101 | 2024-01-01 10:00:00+00:00 | 2024-01-01 08:00:00+00:00 | 2024-01-01 07:30:00+00:00 | Blood | PCR | Units/mL | Positive |
| 102 | 2024-01-02 11:30:00+00:00 | 2024-01-02 09:30:00+00:00 | 2024-01-02 08:15:00+00:00 | Cerebrospinal Fluid | Antigen Detection | mg/L | Negative |
| 103 | 2024-01-03 15:00:00+00:00 | 2024-01-03 13:00:00+00:00 | 2024-01-03 12:45:00+00:00 | Sputum | Gene Amplification | copies/mL | Detected |
| 104 | 2024-01-04 09:45:00+00:00 | 2024-01-04 07:15:00+00:00 | 2024-01-04 06:30:00+00:00 | Urine | Molecular Pathogen ID | ng/mL | Not Detected |
| 105 | 2024-01-05 18:00:00+00:00 | 2024-01-05 16:00:00+00:00 | 2024-01-05 15:00:00+00:00 | Pleural Fluid | Protein Quantification | g/dL | Elevated |
patient assessments Beta
The patient_assessments table captures various assessments performed on patients across different domains, including neurological status, sedation levels, pain, and withdrawal. The table is designed to provide detailed information about the assessments, such as the name of the assessment, the category, and the recorded values.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Primary Identifier. Unique identifier linking assessments to a specific patient hospitalization. | No restriction |
| recorded_dttm | DATETIME | The exact date and time when the assessment was recorded, ensuring temporal accuracy. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| assessment_name | VARCHAR | Assessment Tool Name. The primary name of the assessment tool used (e.g., GCS, NRS, SAT Screen). | No restriction |
| assessment_category | VARCHAR | Maps assessment_name to a standardized list of patient assessments | [List of permissible assessment categories in CLIF] |
| assessment_group | VARCHAR | Broader Assessment Group. This groups the assessments into categories such as Sedation, Neurologic, Pain, etc. | [List of permissible assessment groups in CLIF] |
| numerical_value | DOUBLE | Numerical Assessment Result. The numerical result or score from the assessment component. | Applicable for assessments with numerical outcomes (e.g., 0-10, 3-15) |
| categorical_value | VARCHAR | Categorical Assessment Result. The categorical outcome from the assessment component. | Applicable for assessments with categorical outcomes (e.g., Pass/Fail, Yes/No) |
| text_value | VARCHAR | Textual Assessment Result. The textual explanation or notes from the assessment component. | Applicable for assessments requiring textual data |
Example:
| hospitalization_id | recorded_dttm | assessment_name | assessment_category | assessment_group | numerical_value | categorical_value | text_value |
|---|---|---|---|---|---|---|---|
| 12345 | 2024-12-01 08:15:00+00:00 | NUR RA GLASGOW ADULT EYE OPENING | gcs_eye | Neurological | 4 | NA | NA |
| 12345 | 2024-12-01 08:15:00+00:00 | NUR RA GLASGOW ADULT VERBAL RESPONSE | gcs_verbal | Neurological | 5 | NA | NA |
| 12345 | 2024-12-01 08:15:00+00:00 | NUR RA GLASGOW ADULT BEST MOTOR RESPONSE | gcs_motor | Neurological | 6 | NA | NA |
| 12345 | 2024-12-01 08:15:00+00:00 | NUR RA GLASGOW ADULT SCORING | gcs_total | Neurological | 15 | NA | NA |
| 67890 | 2024-12-01 10:30:00+00:00 | BRADEN ASSESSMENT | braden_total | Nursing Risk | 18 | NA | NA |
| 67890 | 2024-12-01 10:30:00+00:00 | SAT SCREEN | sat_delivery_pass_fail | Sedation | NA | Pass | NA |
patient Beta
This table contains demographic information about the patient that does not vary between hospitalizations. It is inspired by the OMOP Person table
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| patient_id | VARCHAR | Unique identifier for each patient. This is presumed to be a distinct individual. | No restriction |
| race_name | VARCHAR | Patient race string from source data | No restriction |
| race_category | VARCHAR | A standardized CDE description of patient’s race per the US Census | Black or African American, White, American Indian or Alaska Native, Asian, Native Hawaiian or Other Pacific Islander, Unknown, Other |
| ethnicity_name | VARCHAR | Patient ethnicity string from source data | No restriction |
| ethnicity_category | VARCHAR | Description of patient’s ethnicity per the US census definition | Hispanic, Non-Hispanic, Unknown |
| sex_name | VARCHAR | Patient’s biological sex as given in the source data | No restriction |
| sex_category | VARCHAR | Patient’s biological sex | Male, Female, Unknown |
| birth_date | DATE | Patient’s date of birth | Date format should be YYYY-MM-DD |
| death_dttm | DATETIME | Patient’s death date, including time | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| language_name | VARCHAR | Patient’s preferred language | Original string from the source data |
| language_category | VARCHAR | Maps language_name to a standardized list of spoken languages | List of language categories in CLIF |
Example:
| patient_id | race_name | race_category | ethnicity_name | ethnicity_category | sex_category | birth_date | death_dttm | language_name | language_category |
|---|---|---|---|---|---|---|---|---|---|
| 132424 | Black or African-American | Black or African American | Not Hispanic, Latino/a, or Spanish origin | Non-Hispanic | Male | 2145-05-09 | NA | English | English |
| 132384 | White | White | Not Hispanic, Latino/a, or Spanish origin | Non-Hispanic | Female | 2145-03-30 | NA | English | English |
| 542367 | Black or African-American | Black or African American | Not Hispanic, Latino/a, or Spanish origin | Non-Hispanic | Male | 2145-01-29 | NA | English | English |
| 989862 | White | White | Not Hispanic, Latino/a, or Spanish origin | Non-Hispanic | Female | 2145-11-06 | NA | English | English |
| 428035 | More than one Race | Other | Not Hispanic, Latino/a, or Spanish origin | Non-Hispanic | Male | 2145-10-13 | NA | English | English |
position Beta
The position table is a long form (one position per row) longitudinal table that captures all documented position changes of the patient. The table is designed for the explicit purpose of constructing the position_category CDE and identifying patients in prone position.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter. This table only includes those encounters that have proning documented ever. | No restriction |
| recorded_dttm | DATETIME | Date and time when the vital is recorded. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| position_name | VARCHAR | Description of the position from the source data. This field is not used for analysis. | No restriction |
| position_category | VARCHAR | Maps position_name to either prone or not prone. | prone, not_prone |
Example:
| hospitalization_id | recorded_dttm | position_name | position_category |
|---|---|---|---|
| 84 | 2123-06-20 00:00:00+00:00 | Supine–turn R | not_prone |
| 84 | 2123-06-20 06:00:00+00:00 | Supine–turn L | not_prone |
| 84 | 2123-06-20 12:00:00+00:00 | Supine–back | not_prone |
| 84 | 2123-06-20 16:00:00+00:00 | Supine–turn R | not_prone |
| 84 | 2123-06-20 20:00:00+00:00 | Supine–back;Supine–turn intolerant | not_prone |
| 84 | 2123-06-20 22:00:00+00:00 | Supine–turn intolerant,microturn L | not_prone |
| 84 | 2123-06-20 00:00:00+00:00 | Supine–turn intolerant,microturn L;Supine–back | not_prone |
| 84 | 2123-06-20 01:10:00+00:00 | 30 Degrees | not_prone |
respiratory support Beta
The respiratory support table is a wider longitudinal table that captures simultaneously recorded ventilator settings and observed ventilator parameters. The table is designed to capture the most common respiratory support devices and modes used in the ICU. It will be sparse for patients who are not on mechanical ventilation.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter | No restriction |
| recorded_dttm | DATETIME | Date and time when the device settings and/or measurement was recorded. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 |
| device_name | VARCHAR | Raw string of the device. Not used for analysis. | No restriction |
| device_id | VARCHAR | ID variable for device used | No restriction |
| device_category | VARCHAR | Maps device_name to a standardized list of respiratory support device categories | IMV, NIPPV, CPAP, High Flow NC, Face Mask, Trach Collar, Nasal Cannula, Room Air, Other |
| vent_brand_name | VARCHAR | Ventilator model name when device_category is IMV or NIPPV | Optional |
| mode_name | VARCHAR | Raw string of ventilation mode (e.g., CMV volume control) | No restriction |
| mode_category | VARCHAR | Standardized list of modes of mechanical ventilation | Assist Control-Volume Control, Pressure Control, Pressure-Regulated Volume Control, SIMV, Pressure Support/CPAP, Volume Support, Blow by, Other |
| tracheostomy | INT | Indicates if tracheostomy is present | 0 = No, 1 = Yes |
| fio2_set | FLOAT | Fraction of inspired oxygen set (e.g., 0.21) | No restriction, see Expected _set values for each device_category and mode_category |
| lpm_set | FLOAT | Liters per minute set | No restriction, see Expected _set values for each device_category and mode_category |
| tidal_volume_set | FLOAT | Tidal volume set (in mL) | No restriction, see Expected _set values for each device_category and mode_category |
| resp_rate_set | FLOAT | Respiratory rate set (in bpm) | No restriction, see Expected _set values for each device_category and mode_category |
| pressure_control_set | FLOAT | Pressure control set (in cmH2O) | No restriction, see Expected _set values for each device_category and mode_category |
| pressure_support_set | FLOAT | Pressure support set (in cmH2O) | No restriction, see Expected _set values for each device_category and mode_category |
| flow_rate_set | FLOAT | Flow rate set | No restriction, see Expected _set values for each device_category and mode_category |
| peak_inspiratory_pressure_set | FLOAT | Peak inspiratory pressure set (in cmH2O) | No restriction, see Expected _set values for each device_category and mode_category |
| inspiratory_time_set | FLOAT | Inspiratory time set (in seconds) | No restriction, see Expected _set values for each device_category and mode_category |
| peep_set | FLOAT | Positive-end-expiratory pressure set (in cmH2O) | No restriction, see Expected _set values for each device_category and mode_category |
| tidal_volume_obs | FLOAT | Observed tidal volume (in mL) | No restriction |
| resp_rate_obs | FLOAT | Observed respiratory rate (in bpm) | No restriction |
| plateau_pressure_obs | FLOAT | Observed plateau pressure (in cmH2O) | No restriction |
| peak_inspiratory_pressure_obs | FLOAT | Observed peak inspiratory pressure (in cmH2O) | No restriction |
| peep_obs | FLOAT | Observed PEEP (in cmH2O) | No restriction |
| minute_vent_obs | FLOAT | Observed minute ventilation (in liters) | No restriction |
| mean_airway_pressure_obs | FLOAT | Observed mean airway pressure | No restriction |
Notes:
Expected setting values for each device_category and mode_category
device_category== “IMV”
| ventilator_setting | Assist Control-Volume Control | Pressure Support/CPAP | Pressure Control | Pressure-Regulated Volume Control | SIMV | Volume Support |
|---|---|---|---|---|---|---|
| fio2_set | E | E | E | E | E | E |
| tidal_volume_set | E | E | P | E | ||
| resp_rate_set | E | E | E | E | ||
| pressure_control_set | E | P | ||||
| pressure_support_set | E | E | ||||
| flow_rate_set | P | P | ||||
| inspiratory_time_set | P | E | P | |||
| peep_set | E | E | E | E | E | E |
E = Expected ventilator setting for the mode, P = possible ventilator setting for the mode.
device_category== “NIPPV”
mode_category is Pressure Support/CPAP and the fio2_set, peep_set, and either pressure_support_set OR peak_inspiratory_pressure_set (IPAP) is required.
device_category== “CPAP”
mode_category is Pressure Support/CPAP and the fio2_set and peep_set are required.
device_category== “High Flow NC”
mode_category is NA and the fio2_set and lpm_set are required.
device_category== “Face Mask”
mode_category is NAlpm_set is required.fio2_set is possible.
device_category== “Trach Collar” or “Nasal Cannula”
mode_category is NAlpm_set is required
Example:
| hospitalization_id | recorded_dttm | device_name | device_id | device_category | mode_name | mode_category | vent_brand_name | tracheostomy | fio2_set | lpm_set | tidal_volume_set | resp_rate_set | pressure_control_set | pressure_support_set | flow_rate_set | tidal_volume_obs | resp_rate_obs | plateau_pressure_obs | peak_inspiratory_pressure_obs | peep_obs | minute_vent_obs | mean_airway_pressure_obs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12345 | 2024-12-01 08:00:00+00:00 | Ventilator | DEV001 | IMV | CMV Volume Ctrl | Assist Control-Volume Control | Vent A | 1 | 0.50 | 40 | 500 | 18 | 15 | 5 | 50 | 450 | 18 | 20 | 25 | 5 | 9.0 | 12.0 |
| 12345 | 2024-12-01 09:00:00+00:00 | Ventilator | DEV001 | IMV | SIMV | SIMV | Vent A | 1 | 0.45 | 35 | 480 | 20 | 18 | 8 | 55 | 470 | 20 | 21 | 28 | 6 | 10.5 | 14.0 |
| 67890 | 2024-12-01 10:30:00+00:00 | HFNC | DEV002 | High Flow NC | N/A | Other | N/A | 0 | 0.30 | 60 | NA | NA | NA | NA | 60 | NA | NA | NA | NA | NA | NA | NA |
| 67890 | 2024-12-01 11:00:00+00:00 | CPAP | DEV003 | CPAP | CPAP | Pressure Support/CPAP | CPAP X | 0 | 0.40 | 50 | NA | NA | NA | 10 | NA | NA | NA | NA | NA | 8 | NA | NA |
vitals Beta
The vitals table is a long-form (one vital sign per row) longitudinal table.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | ID variable for each patient encounter. | No restriction |
| recorded_dttm | DATETIME | Date and time when the vital is recorded. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| vital_name | VARCHAR | Description of the flowsheet measure from the source data. Not used for analysis. | No restriction |
| vital_category | VARCHAR | Maps vital_name to a list of standard vital sign categories. | temp_c, heart_rate, sbp, dbp, spo2, respiratory_rate, map, height_cm, weight_kg |
| vital_value | FLOAT | Recorded value of the vital. Measurement unit should match the vital category. | temp_c = Celsius, height_cm = Centimeters, weight_kg = Kg, map = mmHg, spo2 = %. No unit for heart_rate, sbp, dbp, respiratory_rate |
| meas_site_name | VARCHAR | Site where the vital is recorded. Optional field with no associated category. | No restriction |
Example:
| hospitalization_id | recorded_dttm | vital_name | vital_category | vital_value | meas_site_name |
|---|---|---|---|---|---|
| 20010012 | 2024-12-01 08:00:00+00:00 | HEIGHT | height_cm | 170.0 | unspecified |
| 20010012 | 2024-12-01 08:15:00+00:00 | WEIGHT | weight_kg | 70.0 | unspecified |
| 20010012 | 2024-12-01 08:30:00+00:00 | PULSE | heart_rate | 72.0 | unspecified |
| 20010012 | 2024-12-01 08:45:00+00:00 | BLOOD PRESSURE (SYSTOLIC) | sbp | 120.0 | unspecified |
| 20010012 | 2024-12-01 08:45:00+00:00 | BLOOD PRESSURE (DIASTOLIC) | dbp | 80.0 | unspecified |
| 20010012 | 2024-12-01 08:50:00+00:00 | RESPIRATORY RATE | respiratory_rate | 16.0 | unspecified |
| 20010012 | 2024-12-01 09:00:00+00:00 | TEMPERATURE | temp_c | 36.8 | unspecified |
| 20010012 | 2024-12-01 09:15:00+00:00 | SPO2 | spo2 | 98.0 | unspecified |
| 20010013 | 2024-12-01 09:30:00+00:00 | MEAN ARTERIAL PRESSURE (MAP) | map | 85.0 | arterial |
Concept Tables
A planned future CLIF table that has yet to be used in a federated project. The table structure and CDE elements are in draft form. Permissible values of category variables may still need to be defined. Seeking conceptual feedback. Significant changes to all aspects of the table are possible.
intake output Concept
The intake_output table is long form table that captures the times intake and output events were recorded, the type of fluid administered or recorded as “out”, and the amount of fluid.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for the hospitalization event. | No restriction |
| intake_dttm | DATETIME | Date and time of intake. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| fluid_name | VARCHAR | Name of the fluid administered. | No restriction |
| amount | DOUBLE | Amount of fluid administered (in mL) | Numeric values in mL |
| in_out_flag | INT | Indicator for intake or output (1 for intake, 0 for output) | 0 = Output, 1 = Intake |
Example:
| hospitalization_id | intake_dttm | fluid_name | amount | in_out_flag |
|---|---|---|---|---|
| 1001 | 2024-01-01 08:00:00+00:00 | Normal Saline | 500 | 1 |
| 1001 | 2024-01-01 10:30:00+00:00 | Urine | 300 | 0 |
| 1002 | 2024-01-05 09:15:00+00:00 | Dextrose | 250 | 1 |
| 1002 | 2024-01-05 14:00:00+00:00 | Urine | 400 | 0 |
| 1003 | 2024-01-10 07:45:00+00:00 | Lactated Ringer’s | 600 | 1 |
| 1003 | 2024-01-10 12:00:00+00:00 | Drainage | 200 | 0 |
invasive hemodynamics Concept
The invasive_hemodynamics table records invasive hemodynamic measurements during a patient’s hospitalization. These measurements represent pressures recorded via invasive monitoring and are expressed in millimeters of mercury (mmHg).
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier linking to the specific hospitalization. | No restriction |
| recorded_dttm | DATETIME | The date and time when the measurement was recorded. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| measure_name | VARCHAR | Description of the site or context of the invasive hemodynamic measurement. | Free text (e.g., Right Atrium) |
| measure_category | VARCHAR | Categorical variable specifying the type of invasive hemodynamic measurement. | CVP, RA, RV, PA_systolic, PA_diastolic, PA_mean, PCWP |
| measure_value | DOUBLE | The numerical value of the invasive hemodynamic measurement in mmHg. | Positive decimal values (e.g., 5.00, 25.65) |
Notes:
- All
measure_valueentries should be recorded in mmHg. - The
measure_categoryfield ensures standardization of invasive hemodynamic data:
1.CVP- Central Venous Pressure
2.RA- Right Atrial Pressure
3.RV- Right Ventricular Pressure
4.PA_systolic- Pulmonary Artery Systolic Pressure
5.PA_diastolic- Pulmonary Artery Diastolic Pressure
6.PA_mean- Pulmonary Artery Mean Pressure
7.PCWP- Pulmonary Capillary Wedge Pressure
Example:
| hospitalization_id | recorded_dttm | measure_name | measure_category | measure_value |
|---|---|---|---|---|
| 12345 | 2024-12-01 08:30:00+00:00 | CVP | CVP | 12.50 |
| 12345 | 2024-12-01 09:00:00+00:00 | Pulmonary Artery-Sys | PA_systolic | 25.00 |
| 12345 | 2024-12-01 09:30:00+00:00 | Wedge | PCWP | 18.75 |
key icu orders Concept
The key_icu_orders table captures key orders related to physical therapy (PT) and occupational therapy (OT) during ICU stays. It includes details about the hospitalization, the timing of the order, the specific name of the order, its category, and the status of the order (completed or sent).
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier linking the order to a specific hospitalization. | No restriction |
| order_dttm | DATETIME | Date and time when the order was placed. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| order_name | VARCHAR | Name of the specific order (e.g., PT Evaluation, OT Treatment). | No restriction |
| order_category | VARCHAR | Category of the order. | Under-development. Some examples include: PT_evaluation, PT_treat, OT_evaluation, OT_treat |
| order_status_name | VARCHAR | Status of the order. | sent, completed |
Example:
| hospitalization_id | order_dttm | order_name | order_category | order_status_name |
|---|---|---|---|---|
| 12345 | 2024-12-15 10:00:00+00:00 | PT Initial Evaluation | PT_evaluation | completed |
| 67890 | 2024-12-16 14:30:00+00:00 | OT Follow-up Treatment | OT_treat | sent |
| 54321 | 2024-12-16 08:00:00+00:00 | PT Mobility Session | PT_treat | completed |
| 98765 | 2024-12-15 11:15:00+00:00 | OT Cognitive Assessment | OT_evaluation | sent |
medication admin intermittent Concept
This table has exactly the same schema as medication_admin_continuous described below. The consortium decided to separate the medications that are administered intermittently from the continuously administered medications. The mCIDE for medication_category for intermittent meds can be found here.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| N | INT | This is a placeholder column. See documentation above for schema details. |
medication orders Concept
This table records the ordering (not administration) of medications. The table is in long form (one medication order per row) longitudinal table. Linkage to the medication_admin_continuous and medication_admin_intermittent tables is through the med_order_id field.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for each hospitalization, linking medication orders to a specific encounter | No restriction |
| med_order_id | VARCHAR | Unique identifier for each medication order | No restriction |
| order_start_dttm | DATETIME | Date and time when the medication order was initiated. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| order_end_dttm | DATETIME | Date and time when the medication order ended or was discontinued. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| ordered_dttm | DATETIME | Date and time when the medication was actually ordered. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| med_name | VARCHAR | Name of the medication ordered | No restriction |
| med_category | VARCHAR | Maps med_name to a list of permissible medication names | Combined CDE of medication_admin_continuous and medication_admin_intermittent |
| med_group | VARCHAR | Limited number of medication groups identified by the CLIF consortium | No restriction |
| med_order_status_name | VARCHAR | Status of the medication order, e.g. held, given | No restriction |
| med_order_status_category | VARCHAR | Maps med_order_status_name to a standardized list of medication order statuses | Under-development |
| med_route_name | VARCHAR | Route of administration for the medication | No restriction. Examples include Oral, Intravenous |
| med_dose | DOUBLE | Dosage of the medication ordered | Numeric |
| med_dose_unit | VARCHAR | Unit of measurement for the medication dosage | Examples include mg, mL, units |
| med_frequency | VARCHAR | Frequency with which the medication is administered, as per the order | Examples include Once Daily, Every 6 hours |
| prn | BOOLEAN | Indicates whether the medication is to be given as needed (PRN) | 0 = No, 1 = Yes |
Example:
| hospitalization_id | med_order_id | order_start_dttm | order_end_dttm | ordered_dttm | med_name | med_category | med_group | med_order_status_name | med_order_status_category | med_route_name | med_dose | med_dose_unit | med_frequency | prn |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12345 | 456789 | 2023-10-01 14:00:00+00:00 | 2023-10-02 14:00:00+00:00 | 2023-10-01 13:30:00+00:00 | Norepinephrine 8 mg/250 mL | norepinephrine | vasoactives | active | ongoing | Intravenous | 8.0 | mg/mL | Continuous | 0 |
| 12346 | 456790 | 2023-10-01 16:00:00+00:00 | 2023-10-02 10:00:00+00:00 | 2023-10-01 15:30:00+00:00 | Vancomycin 1 g IV | vancomycin | antibiotics | active | ongoing | Intravenous | 1.0 | g | Every 12 hours | 0 |
| 12347 | 456791 | 2023-10-02 08:00:00+00:00 | 2023-10-03 08:00:00+00:00 | 2023-10-02 07:30:00+00:00 | Furosemide 40 mg IV | furosemide | diuretics | discontinued | discontinued | Intravenous | 40.0 | mg | Once Daily | 0 |
| 12348 | 456792 | 2023-10-02 12:00:00+00:00 | 2023-10-02 18:00:00+00:00 | 2023-10-02 11:45:00+00:00 | Insulin Regular 100 units/mL SC | insulin | endocrine | held | held | Subcutaneous | 100.0 | units/mL | As Needed | 1 |
| 12349 | 456793 | 2023-10-03 08:00:00+00:00 | 2023-10-03 20:00:00+00:00 | 2023-10-03 07:30:00+00:00 | Acetaminophen 1 g PO | acetaminophen | analgesics | active | ongoing | Oral | 1.0 | g | Every 6 hours | 0 |
| 12350 | 456794 | 2023-10-03 10:00:00+00:00 | 2023-10-03 18:00:00+00:00 | 2023-10-03 09:45:00+00:00 | Heparin 5,000 units SC | heparin | anticoagulant | active | ongoing | Subcutaneous | 5000.0 | units | Every 8 hours | 0 |
| 12351 | 456795 | 2023-10-03 14:00:00+00:00 | 2023-10-03 22:00:00+00:00 | 2023-10-03 13:30:00+00:00 | Morphine Sulfate 2 mg IV | morphine | analgesics | active | ongoing | Intravenous | 2.0 | mg | As Needed | 1 |
| 12352 | 456796 | 2023-10-03 20:00:00+00:00 | 2023-10-04 08:00:00+00:00 | 2023-10-03 19:45:00+00:00 | Dexamethasone 10 mg IV | dexamethasone | steroids | active | ongoing | Intravenous | 10.0 | mg | Once Daily | 0 |
procedures Concept
A longitudinal record of each bedside ICU procedure performed on the patient (e.g. central line placement, chest tube placement). Note that this table is not intended to capture the full set of procedures performed on inpatients.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for each hospitalization, linking the procedure to a specific encounter | No restriction |
| procedure_name | VARCHAR | Name of the procedure performed on the patient | Examples include Central Line Placement |
| procedure_category | VARCHAR | Maps procedure_name to a list of standardized procedures | CDE under development |
| diagnosis | VARCHAR | The diagnosis or reason for performing the procedure | No restriction |
| start_dttm | DATETIME | Date and time when the procedure was initiated. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
Example:
| hospitalization_id | procedure_name | procedure_category | diagnosis | start_dttm |
|---|---|---|---|---|
| 1001 | Central Line Placement | Vascular Access | Sepsis with hypotension | 2024-01-01 08:00:00 |
| 1001 | Chest Tube Placement | Respiratory Support | Pneumothorax | 2024-01-01 10:00:00 |
| 1002 | Endotracheal Intubation | Airway Management | Acute Respiratory Failure | 2024-01-05 09:30:00 |
| 1002 | Paracentesis | Diagnostic Procedure | Suspected peritonitis | 2024-01-05 11:00:00 |
| 1003 | Arterial Line Placement | Vascular Access | Hemodynamic Monitoring | 2024-01-10 07:00:00 |
provider Concept
Continuous start stop record of every provider who cared for the patient.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for each hospitalization, linking the provider to a specific encounter | No restriction |
| provider_id | VARCHAR | Unique identifier for each provider. This represents individual healthcare providers | No restriction |
| start_dttm | DATETIME | Date and time when the provider’s care or involvement in the patient’s case began. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| stop_dttm | DATETIME | Date and time when the provider’s care or involvement in the patient’s case ended. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| provider_role_name | VARCHAR | The original string describing the role or specialty of the provider during the hospitalization | No restriction |
| provider_role_category | VARCHAR | Maps provider_role_name to list of standardized provider roles | Under development |
Example:
| hospitalization_id | start_dttm | stop_dttm | provider_role_name | provider_role_category |
|---|---|---|---|---|
| 1001014 | 2023-05-01 08:00:00+00:00 | 2023-05-01 20:00:00+00:00 | Attending Physician | Attending |
| 1001014 | 2023-05-01 08:00:00+00:00 | 2023-05-02 08:00:00+00:00 | Resident Physician | Resident |
| 1001014 | 2023-05-01 08:00:00+00:00 | 2023-05-03 08:00:00+00:00 | Nurse Practitioner | Nurse Practitioner |
| 1002025 | 2023-06-10 09:00:00+00:00 | 2023-06-10 21:00:00+00:00 | Critical Care Specialist | Critical Care |
| 1002025 | 2023-06-10 09:00:00+00:00 | 2023-06-11 09:00:00+00:00 | Respiratory Therapist | Respiratory Therapy |
| 1003036 | 2023-07-15 07:30:00+00:00 | 2023-07-15 19:30:00+00:00 | Attending Physician | Attending |
| 1003036 | 2023-07-15 07:30:00+00:00 | 2023-07-16 07:30:00+00:00 | Charge Nurse | Nurse |
| 1004047 | 2023-08-20 10:00:00+00:00 | 2023-08-20 22:00:00+00:00 | Physical Therapist | Therapy |
sensitivity Concept
This table is used to store the susceptibility results of the organisms identified in the Microbiology Culture table and may be renamed to Microbiology_Susceptibility
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| culture_id | VARCHAR | Unique identifier linking to the culture from which the sensitivity test was performed | No restriction |
| antibiotic | VARCHAR | Name of the antibiotic tested for sensitivity | Examples include Penicillin, Vancomycin |
| sensitivity | VARCHAR | The result of the sensitivity test, indicating the organism’s resistance or susceptibility | Resistant, Intermediate, Susceptible |
| mic | DOUBLE | Minimum Inhibitory Concentration (MIC) value, which measures the lowest concentration of an antibiotic needed to inhibit growth | Numeric |
Example:
| culture_id | antibiotic | sensitivity | mic |
|---|---|---|---|
| 1001 | Penicillin | Susceptible | 0.25 |
| 1001 | Vancomycin | Resistant | 8.0 |
| 1002 | Amoxicillin | Intermediate | 4.0 |
| 1003 | Ciprofloxacin | Susceptible | 0.5 |
| 1004 | Gentamicin | Resistant | 16.0 |
therapy details Concept
The therapy_details table is a wide longitudinal table that captures the details of therapy sessions. The table is designed to capture and categorize the most common therapy elements used in the ICU.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier for the hospitalization event. | No restriction |
| session_start_dttm | DATETIME | Date and time when the therapy session started. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| therapy_element_name | VARCHAR | Name of the therapy element. | No restriction |
| therapy_element_category | VARCHAR | Category of the therapy element. | No restriction |
| therapy_element_value | VARCHAR | Value associated with the therapy element. | No restriction |
Example:
| hospitalization_id | session_start_dttm | therapy_element_name | therapy_element_category | therapy_element_value |
|---|---|---|---|---|
| 1001 | 2024-01-01 08:00:00+00:00 | Physical Therapy | Rehabilitation | 45.0 |
| 1001 | 2024-01-01 10:00:00+00:00 | Respiratory Therapy | Respiratory Support | 3.0 |
| 1002 | 2024-01-05 09:30:00+00:00 | Occupational Therapy | Rehabilitation | 60.0 |
| 1002 | 2024-01-05 11:00:00+00:00 | Speech Therapy | Rehabilitation | 30.0 |
| 1003 | 2024-01-10 07:00:00+00:00 | Ventilation Support | Respiratory Support | 2.5 |
transfusion Concept
This table provides detailed information about transfusion events linked to specific hospitalizations.
| Column | Type | Description | Permissible Values |
|---|---|---|---|
| hospitalization_id | VARCHAR | Unique identifier linking the transfusion event to a specific hospitalization in the CLIF database. | No restriction |
| transfusion_start_dttm | DATETIME | The date and time the transfusion of the blood component began. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| transfusion_end_dttm | DATETIME | The date and time the transfusion of the blood component ended. All datetime variables must be timezone-aware and set to UTC. | Datetime format should be YYYY-MM-DD HH:MM:SS+00:00 (UTC) |
| component_name | VARCHAR | The name of the blood component transfused. | E.g., Red Blood Cells, Plasma, Platelets |
| attribute_name | VARCHAR | Attributes describing modifications to the component. | E.g., Leukocyte Reduced, Irradiated |
| volume_transfused | DOUBLE | The volume of the blood component transfused. | Numeric, e.g., 300 |
| volume_units | VARCHAR | The unit of measurement for the transfused volume. | E.g., mL |
| product_code | VARCHAR | ISBT 128 Product Description Code representing the specific blood product. | E.g., E0382 |
Example:
| hospitalization_id | transfusion_start_dttm | transfusion_end_dttm | component_name | attribute_name | volume_transfused | volume_units | product_code |
|---|---|---|---|---|---|---|---|
| 123456 | 2024-12-03 08:30:00+00:00 | 2024-12-03 10:00:00+00:00 | Red Blood Cells | Leukocyte Reduced | 300 | mL | E0382 |
| 789012 | 2024-12-04 14:00:00+00:00 | 2024-12-04 16:30:00+00:00 | Platelets | Irradiated | 250 | mL | P0205 |
| 456789 | 2024-12-05 12:15:00+00:00 | 2024-12-05 13:45:00+00:00 | Plasma | 200 | mL | F0781 |
Future Proposed Tables
These are tables without any defined structure that the consortium has not yet committed to implementing.
Clinical Decision Support: This table will capture the actions of clinical decision support tools embedded in the EHR. The table will have the following fields: cds_name, cds_category, cds_value, cds_trigger_ddtm.
